KALLITHEA
MANUFACTURED BY NIKI ROTOR AVIATION
Kallithea (from Greek “the best view”) is an elegant gyroplane with a spacious cockpit and marvelous view. From the carefully sculpted carbon fiber seats, to the full set of dual flight controls with 4 way trim, to the strong cabin heating system the Kallithea is meant to cruise effortlessly through the sky year round. With the choice of basic to the most advanced integrated avionics, the Kallithea can fit a wide range of budgets and desires.
BREATHTAKING VIEWS
The expansive view from either seat of the Kallithea nearly overloads the senses. From the comfort of an enclosed cabin the view is nearly unrestricted throughout your entire field of view.
fuel injected engine
The Turbocharged Rotax 915iS provides unprecedented levels of performance without sacrificing reliability or redundancy.
all in one avionics
The Garmin Flight Deck brings situational awareness and access to information to another level. With the large touchscreen display the instruments are easy to scan. Alerts to oncoming airspace, terrain, and other air traffic keep you informed to stay safe.
advanced materials
Extensive use of composites, primarily carbon fiber, give the Kallithea great strength while keeping usable payload high. The composite materials provide greater longevity than their metallic counterparts.
INNOVATIVE DESIGN
The Kallithea has many unique design features that collectively create the most memorable flight experience whether traveling locally or cross-country.
kallithea
GENERAL SPECIFICATIONS
Seats
Two/Tandem
Empty Weight
650-800lbs
Max Takeoff Weight
1235 - 1320 lbs
Maximum Pilot Weight
286 lbs
Useful Load
500-585 lbs
PERFORMANCE SPECIFICATIONS
Max Speed
120 mph
Cruise Speed
75-110 mph
Minimum Speed
30 mph
Range
270 sm @ 100 mph
Maximum Climb Rate
600 – 2000 ft/min
Service Ceiling
10,000 – 18,000 feet
Take off Roll (MGTW no wind)
490 feet
Landing Roll (no wind)
65 feet
Maximum Endurance
4 hours + 30 minute reserve
FUEL
Fuel Consumption
3 – 6 gallons/ hour
Fuel Type
Premium Automotive
Fuel Tank Capacity
15.3 gallons
ENGINE
Engine Options
Rotax 912ULS / 914UL / 912iS / 915iS
Horsepower
100 / 115 / 100 / 141
Pre-rotation Range
200-300 RPM
AVIONICS
Standard
Kanardia Indu, TRIG Comm Radio TY91, TRIG Transponder w/ ADSB
Optional
Garmin Flight Deck Suite
PRE-ROTATION & ROTORBLADE
Pre-rotation Engagement
Mechanical (foot pedal)
Pre-rotation Protection
No
Pre-rotation Interruptible
Yes
Pre-rotation From Rear Seat
No
Rotor Type
NACA 8H12 extruded aluminum (Artur Trendak)
WARRANTY
Warranty of the Engine
As per Rotax (18 months / 200 hours)
Warranty of Airframe
300 hours / 2 years
DIMENSIONS
Length
15 feet 11 inches
Height
9 feet 2 inches
Width
5 feet 11 inches
Rotor Diameter
28 feet
Airframe Construction Material
Carbon Fiber
Hull
Carbon Fiber
Tail
Carbon Fiber
Propeller Material
Composite
Power Outlet Voltage
12 volt
Nav/Strobe/Landing Lights
Yes
